2. To load labels in the tray, insert labels face up with the top edge toward the back. Stack the labels
against the left-rear corner of the tray as shown.
3. Slide the tray back into the printer.
4. At the control panel, select the correct paper type and color. Ensure that the paper type is set to
Labels.
Note: To change the paper settings when the tray is set to Dedicated mode, refer to
Configuring Tray Settings.
5. To confirm the settings, touch OK.
6. To return to the Home screen, press the Home button.
Loading Labels in the Bypass Tray
1. Open the bypass tray, then for larger sizes of paper, pull out the extension tray. Remove any
paper that is a different size or type.
2. Move the width guides to the edges of the tray.
177
