Xerox VersaLink C7000 Customer Expectation And Installation Guide

Customer Expectation and Installation Guide 14
Finishing Specifications
Stacker
Output Trays (Standard)
Stacking Trays
 Dual Offset Catch Tray – up to 250 sheets each
 Lower Tray offsets
Integrated Office Finisher (Optional)
Stacking Tray
500 sheets of 20 lb. bond / 80 gsm – 8.5 x 11 in. / A4 or 250 sheets of 20 lb. bond / 80 gsm – 11 x 17 in. / A3
Sizes
3.5 x 3.9 in. to 11.7 x 17 in. / 89 x 98 mm to 297 x
432 mm
Weights
16 lb. bond to 80 lb. cover / 60 to 256 gsm
Stapling
 Single
 Auto stapling: 50 sheets maximum: Letter / A4 / B5-size sheets (less than 90 gsm or (2) 220 gsm covers)
 30 sheets maximum: Legal / Tabloid / A3 / B4-size sheets (less than 90 gsm or (2) 220 gsm covers)
 Max paper weight that can be stapled is 220gsm. Performance of stapling 50 sheets of paper exceeding 90gsm cannot be
guaranteed.
 Max paper size that can be stapled is 11x17” (A3)
 Offset between sets is available.
 Staple mode: Offset is supported unless paper is longer than 297mm or Letter SEF is used.
 Non-staple mode: Offset of sheets larger than
190 x 148mm is supported.
Office Finisher LX (Optional)
Capacity
Stacking Tray: 2,000 sheets unstapled or 1,000 sheets single stapled or 750 sheets dual stapled (8.5 x 11 in. / A4)
Center Lower Tray is not available when Office Finisher LX is installed
Sizes
7.2 x 8.3 in. to 11.7 x 17 in. / 182 x 210 mm to
297 x 432 mm
Weights
16 lb bond to 80 lb cover / 60 to 256 gsm
Multi-position
Stapling
50 sheets of 24 lb. bond / 90 gsm
Hole Punch
(Optional)
North America:
Europe:
 2-3 Hole Punch
 2-4 Hole Punch
 Up to 65 lb cover (176gsm) available to right center tray
Booklet Maker for Office Finisher LX (Score/Crease, Saddle-stitch Staple) (Optional)
7
Capacity
40 booklets (2-15 sheets per booklet – 20 lb. / 80 gsm or less)
Sizes
 Letter – 8.5 x 11 in. / A4 SEF
 Legal – 8.5 x 14 in. / B4 SEF
 Ledger – 11 x 17 in. / A3 SEF
Saddle-stitch
Stapling
 2-15 sheets / 8-60 page booklet
 16 lb. bond to 24 lb. bond / 60 to 90 gsm
Score / Crease
 1-15 sheets / unstapled
 Creases up to 28lb (105 gsm)
Stapler
Convenience Stapler (Optional - Includes Work Surface)
Capacity
50-sheet stapling
 5,000 staples
 Requires a separate outlet
7
Roller marks may be visible on output sheets when coated papers are output to the Stacker

Xerox VersaLink C7000 Specifications

General

Package depth	770 mm
Package width	710 mm
Package height	945 mm
Package weight	71000 g
Country of origin	Vietnam
Maximum resolution	1200 x 2400 DPI
Optional connectivity	Wireless LAN
Maximum input capacity	2180 sheets
Standard input capacity	620 sheets
Standard output capacity	500 sheets
Storage temperature (T-T)	0 - 35 °C
Operating temperature (T-T)	10 - 32 °C
Sustainability certificates	ENERGY STAR
Operating relative humidity (H-H)	10 - 85 %
Print speed (black, normal quality, A4/US Letter)	35 ppm
Color	Yes
Print technology	Laser
Duplex printing mode	Auto
Warm-up time (from sleep mode)	12 s
Time to first page (black, normal)	5.1 s
Time to first page (color, normal)	7.6 s
PCL fonts	83
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	153000 pages per month
Recommended duty cycle	0 - 10000 pages per month
Number of PostScript fonts	136
Number of print cartridges	4
Page description languages	HP-GL, PCL 5e, PCL 6, PostScript 3, TIFF, XPS
Standard interfaces	Ethernet, USB 3.2 Gen 1 (3.1 Gen 1)
Paper input type	Paper tray
Total number of input trays	1
Multi-Purpose tray input capacity	100 sheets
Custom media width	88.9 - 297 mm
Custom media length	98.4 - 431.8 mm
Paper tray media types	Bond paper, Card stock, Glossy paper, Heavy paper, Labels, Letterhead, Lightweight paper, Plain paper, Pre-Printed, Recycled paper
Paper tray media weight	60 - 256 g/m²
ISO A-series sizes (A0...A9)	A3, A4
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 216 g/m²
Wi-Fi	No
Cabling technology	10/100/1000Base-T(X)
Security algorithms	256-bit AES, FIPS 140-2, HTTPS, IPSec, SNMPv3, SSL/TLS
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Mopria Print Service
Supported network protocols (IPv4)	TCP/IP, HTTP/HTTPS, Internet Printing Protocol, LPR/LPD, Raw Socket Printing/Port 9100, IPv4/IPv6, WSD LDAP, FTP
Supported network protocols (IPv6)	IPv6
Internal memory	2048 MB
Processor cores	2
Processor frequency	1050 MHz
Sound power level (standby)	26 dB
Sound pressure level (printing)	52.5 dB
Current rating	8 A
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	94 W
Power consumption (printing)	1600 W
Power consumption (PowerSave)	1 W
Control type	Touch
Certification	WHQL, IPv6 Ready, Bonjour, Mopria, Wi-Fi Direct, Apple AirPrint, Cerner, MEDITECH, SAP, FIPS 140-2, Blue Angel, ECOLOGO, EPEAT
Product color	Blue, White
Market positioning	Business
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra
Server operating systems supported	Windows 2000 Server, Windows Server 2003, Windows Server 2008, Windows Server 2008 R2, Windows Server 2012
Windows operating systems supported	Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64
Cables included	AC

Weight and Dimensions

Depth	670.8 mm
Width	590 mm
Height	637 mm
Weight	54300 g
