Xerox VersaLink C7000 User Manual

Electrical Specifications
PPoowweerr CCoonnssuummppttiioonn
• 110–127 V:
– Maximum power consumption: 1.6 kW
– Sleep mode: 1.0 W or less
– Low-Power mode: 70 W or less
– Standby mode: 94 W or less
• 220–240 V:
– Maximum power consumption: 1.6 kW
– Sleep mode: 1.4 W or less
– Low-Power mode: 70 W or less
– Standby mode: 94 W or less
PPoowweerr SSuuppppllyy VVoollttaaggee aanndd FFrreeqquueennccyy
Power Supply Voltage Frequency Current Required
110–127 VAC +6%/-10%
(99–135 VAC)
50/60 Hz +/-3% 12 A
220–240 VAC +/-10%
(198–264 VAC)
50 Hz +/-3% 8 A
EENNEERRGGYY SSTTAARR QQuuaalliiffiieedd PPrroodduucctt
This product is ENERGY STAR
®
qualified under the ENERGY STAR Program
Requirements for Imaging Equipment.
The ENERGY STAR and ENERGY STAR mark are registered United States trademarks.
The ENERGY STAR Imaging Equipment Program is a team effort between United States,
European Union, and Japanese governments and the office equipment industry to promote
energy-efficient copiers, printers, fax, multifunction printers, personal computers, and
monitors. Reducing product energy consumption helps combat smog, acid rain, and long-
term changes to the climate by decreasing the emissions that result from generating
electricity.
ENERGY STAR settings are preset on Xerox
®
equipment at the factory to switch to Power Saver modes
after 2 minutes from the last copy or print.
Note: The ENERGY STAR qualification only applies to printer configurations with automatic 2-
sided printing.
Xerox
®
VersaLink
®
C7000 Color Printer
User Guide
191
Specifications

Xerox VersaLink C7000 Specifications

General

Package depth	770 mm
Package width	710 mm
Package height	945 mm
Package weight	71000 g
Country of origin	Vietnam
Maximum resolution	1200 x 2400 DPI
Optional connectivity	Wireless LAN
Maximum input capacity	2180 sheets
Standard input capacity	620 sheets
Standard output capacity	500 sheets
Storage temperature (T-T)	0 - 35 °C
Operating temperature (T-T)	10 - 32 °C
Sustainability certificates	ENERGY STAR
Operating relative humidity (H-H)	10 - 85 %
Print speed (black, normal quality, A4/US Letter)	35 ppm
Color	Yes
Print technology	Laser
Duplex printing mode	Auto
Warm-up time (from sleep mode)	12 s
Time to first page (black, normal)	5.1 s
Time to first page (color, normal)	7.6 s
PCL fonts	83
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	153000 pages per month
Recommended duty cycle	0 - 10000 pages per month
Number of PostScript fonts	136
Number of print cartridges	4
Page description languages	HP-GL, PCL 5e, PCL 6, PostScript 3, TIFF, XPS
Standard interfaces	Ethernet, USB 3.2 Gen 1 (3.1 Gen 1)
Paper input type	Paper tray
Total number of input trays	1
Multi-Purpose tray input capacity	100 sheets
Custom media width	88.9 - 297 mm
Custom media length	98.4 - 431.8 mm
Paper tray media types	Bond paper, Card stock, Glossy paper, Heavy paper, Labels, Letterhead, Lightweight paper, Plain paper, Pre-Printed, Recycled paper
Paper tray media weight	60 - 256 g/m²
ISO A-series sizes (A0...A9)	A3, A4
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 216 g/m²
Wi-Fi	No
Cabling technology	10/100/1000Base-T(X)
Security algorithms	256-bit AES, FIPS 140-2, HTTPS, IPSec, SNMPv3, SSL/TLS
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Mopria Print Service
Supported network protocols (IPv4)	TCP/IP, HTTP/HTTPS, Internet Printing Protocol, LPR/LPD, Raw Socket Printing/Port 9100, IPv4/IPv6, WSD LDAP, FTP
Supported network protocols (IPv6)	IPv6
Internal memory	2048 MB
Processor cores	2
Processor frequency	1050 MHz
Sound power level (standby)	26 dB
Sound pressure level (printing)	52.5 dB
Current rating	8 A
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	94 W
Power consumption (printing)	1600 W
Power consumption (PowerSave)	1 W
Control type	Touch
Certification	WHQL, IPv6 Ready, Bonjour, Mopria, Wi-Fi Direct, Apple AirPrint, Cerner, MEDITECH, SAP, FIPS 140-2, Blue Angel, ECOLOGO, EPEAT
Product color	Blue, White
Market positioning	Business
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra
Server operating systems supported	Windows 2000 Server, Windows Server 2003, Windows Server 2008, Windows Server 2008 R2, Windows Server 2012
Windows operating systems supported	Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64
Cables included	AC

Weight and Dimensions

Depth	670.8 mm
Width	590 mm
Height	637 mm
Weight	54300 g
