Xerox VersaLink C7000 User Manual

Item Name
Description
When the printer is powered on, pressing this button displays
a menu on the control panel. From this menu, you can
choose to enter Sleep mode, restart, or power off the printer.
When the printer is powered on, but in a low-power mode or
Sleep mode, pressing this button wakes the printer.
When the printer is powered on, holding this button for 10-
seconds turns off the printer.
This button blinks to indicate the power status of the printer.
When the light blinks slowly, the printer is in low-power mode
or Sleep mode.
When the light blinks rapidly, the printer is powering down, or
exiting a low-power mode.
5 Status LED This light blinks blue or amber to indicate printer status.
Blue
Blinks blue once to acknowledge a successful Authentication
request.
Blinks blue once slowly for a print job initiated at the control
panel.
Blinks blue twice slowly for a print job received from the
network.
Blinks blue rapidly while the printer is powering up, or to
signal detection of a Wi-Fi Direct connection request.
Amber
Blinks amber to indicate an error condition or warning that
requires your attention. For example, an out of toner
condition, a paper jam, or out of paper for the current job.
It also blinks amber to indicate a system error, which typically
is associated with an error code.
6 Notification Banner Notifications and messages are displayed in a pop-up banner
below the apps area. To view the full notification, touch the
center of the banner. After you have reviewed the
information, touch X to close.
7 Pause Icon When a job is being processed, a Pause icon appears in the
notification banner area. To pause the current job, touch the
Pause icon. The job pauses with the option to resume or
delete the job.
26
Xerox
®
VersaLink
®
C7000 Color Printer
User Guide
Getting Started

Xerox VersaLink C7000 Specifications

General

Package depth	770 mm
Package width	710 mm
Package height	945 mm
Package weight	71000 g
Country of origin	Vietnam
Maximum resolution	1200 x 2400 DPI
Optional connectivity	Wireless LAN
Maximum input capacity	2180 sheets
Standard input capacity	620 sheets
Standard output capacity	500 sheets
Storage temperature (T-T)	0 - 35 °C
Operating temperature (T-T)	10 - 32 °C
Sustainability certificates	ENERGY STAR
Operating relative humidity (H-H)	10 - 85 %
Print speed (black, normal quality, A4/US Letter)	35 ppm
Color	Yes
Print technology	Laser
Duplex printing mode	Auto
Warm-up time (from sleep mode)	12 s
Time to first page (black, normal)	5.1 s
Time to first page (color, normal)	7.6 s
PCL fonts	83
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	153000 pages per month
Recommended duty cycle	0 - 10000 pages per month
Number of PostScript fonts	136
Number of print cartridges	4
Page description languages	HP-GL, PCL 5e, PCL 6, PostScript 3, TIFF, XPS
Standard interfaces	Ethernet, USB 3.2 Gen 1 (3.1 Gen 1)
Paper input type	Paper tray
Total number of input trays	1
Multi-Purpose tray input capacity	100 sheets
Custom media width	88.9 - 297 mm
Custom media length	98.4 - 431.8 mm
Paper tray media types	Bond paper, Card stock, Glossy paper, Heavy paper, Labels, Letterhead, Lightweight paper, Plain paper, Pre-Printed, Recycled paper
Paper tray media weight	60 - 256 g/m²
ISO A-series sizes (A0...A9)	A3, A4
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 216 g/m²
Wi-Fi	No
Cabling technology	10/100/1000Base-T(X)
Security algorithms	256-bit AES, FIPS 140-2, HTTPS, IPSec, SNMPv3, SSL/TLS
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Mopria Print Service
Supported network protocols (IPv4)	TCP/IP, HTTP/HTTPS, Internet Printing Protocol, LPR/LPD, Raw Socket Printing/Port 9100, IPv4/IPv6, WSD LDAP, FTP
Supported network protocols (IPv6)	IPv6
Internal memory	2048 MB
Processor cores	2
Processor frequency	1050 MHz
Sound power level (standby)	26 dB
Sound pressure level (printing)	52.5 dB
Current rating	8 A
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	94 W
Power consumption (printing)	1600 W
Power consumption (PowerSave)	1 W
Control type	Touch
Certification	WHQL, IPv6 Ready, Bonjour, Mopria, Wi-Fi Direct, Apple AirPrint, Cerner, MEDITECH, SAP, FIPS 140-2, Blue Angel, ECOLOGO, EPEAT
Product color	Blue, White
Market positioning	Business
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra
Server operating systems supported	Windows 2000 Server, Windows Server 2003, Windows Server 2008, Windows Server 2008 R2, Windows Server 2012
Windows operating systems supported	Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64
Cables included	AC

Weight and Dimensions

Depth	670.8 mm
Width	590 mm
Height	637 mm
Weight	54300 g
