Xerox WorkCentre 3335 Service Manual

Xerox Internal Use Only
Prepared By:
Xerox Corporation
Digital, Creative, and Language Services - North America
800 Phillips Road, Building 218-01A
Webster, New York 14580
ISO9001 and ISO027001 Certified
© 2016 by Xerox Corporation. All rights reserved. XEROX® and XEROX and Design®, Phaser®, CentreWare®, PrintingScout®, Walk-Up®,
WorkCentre®, FreeFlow®, SMARTsend®, Scan to PC Desktop®, ColorQube, Global Print Driver®, and Mobile Express Driver are trademarks of Xerox
Corporation in the United States and/or other countries
Unpublished rights reserved under the copyright laws of the United States. Contents of this publication may not be reproduced in any form without
permission of Xerox Corporation.
Copyright protection claimed includes all forms and matters of copyrighted materials and information now allowed by statutory or judicial law or
hereinafter granted, including without limitation, material generated from the software programs which are displayed on the screen such as styles,
templates, icons, screen displays, looks, etc.
Xerox technical training materials and service manuals are intended for use by authorized Xerox service technicians and service partners only and are
not for resale. These materials may not be distributed, copied, or otherwise reproduced without prior written consent from Xerox Corporation.
Adobe Reader®, Adobe Type Manager®, ATM™, and PostScript® are trademarks of Adobe Systems Incorporated in the United States and/or other
countries.
Apple®, AppleTalk®, Bonjour®, EtherTalk®, LaserWriter®, LocalTalk®, Macintosh®, Mac OS®, and TrueType® are trademarks of Apple Computer,
Inc. in the United States and/or other countries.
HP-GL®, HP-UX®, and PCL® are trademarks of Hewlett-Packard Corporation in the United States and/or other countries.
Windows®, Vista™, and Windows Server™ are trademarks of Microsoft Corporation in the United States and/or other countries.
Novell®, NetWare®, NDPS®, NDS®, Novell Directory Services®, IPX™, and Novell Distributed Print Services™ are trademarks of Novell, Incorporated
in the United States and/or other countries.
Sun
SM
, Sun Microsystems™, and Solaris™ are trademarks of Sun Microsystems, Incorporated in the United States and/or other countries.
SWOP® is a trademark of SWOP, Inc.
UNIX® is a registered trademark in the US and other countries, licensed exclusively through X/Open Company Limited.
As an ENERGY STAR® partner, Xerox Corporation has determined that this product meets the ENERGY STAR guidelines for energy efficiency. The
ENERGY STAR name and logo are registered U.S. marks.
PANTONE® Colors generated may not match PANTONE-identified standards. Consult current PANTONE Publications for accurate color. PANTONE®
and other Pantone, Inc. trademarks are the property of Pantone, Inc. © Pantone, Inc., 2000.

Xerox WorkCentre 3335 Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	6.5 s
Print speed (black, normal quality, A4/US Letter)	33 ppm
Maximum copy resolution	600 x 600 DPI
Time to first copy (black, normal)	13 s
Scan to	E-mail, FTP, File, USB
Scanner type	Flatbed & ADF scanner
Output color depth	8 bit
Image formats supported	JPG, TIF
Maximum scan resolution	4800 x 4800 DPI
Faxing	-
Modem speed	33.6 Kbit/s
Auto-redialing	Yes
Fax coding methods	JBIG, JPEG, MH, MMR (Fax coding method), MR
Fax resolution (black)	300 x 300 DPI
Fax speed dialing (max numbers)	200
Maximum duty cycle	50000 pages per month
Page description languages	PCL 5e, PCL 6, PostScript 3
Printer management	IP Filtering, Secure IPP, SS, Secure HTTPS (SSL/TLS)
Internal memory	1500 MB
Processor frequency	1000 MHz
Total input capacity	300 sheets
Total output capacity	150 sheets
Maximum input capacity	850 sheets
Auto document feeder (ADF) input capacity	50 sheets
Storage temperature (T-T)	0 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	20 - 80 %
Display	LCD
Product color	Blue, White
Market positioning	Business
Certification	CE Mark applicable to Low Voltage Directive (2006/95/EC), EMC Directive 2004/108/EC, FCC Part 15, Class B, FCC Part 68, GOST, GS Mark, R&TTE Directive 1999/5/EC, UL 60950-1/CSA 60950-1-07, 2nd Edition
Sustainability certificates	ENERGY STAR
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (average operating)	700 W
Standard interfaces	Ethernet, USB, Wireless LAN
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print
Paper tray media types	Card stock, Plain paper, Recycled paper
Maximum ISO A-series paper size	A4

Weight and Dimensions

Depth	420.6 mm
Width	414.6 mm
Height	449 mm
Weight	15510 g
