Xerox WorkCentre 3335 Service Manual

General Information
Xerox Internal Use Only Phaser 3330 and WorkCentre 3335/3345
Service Manual
1-39
Printing Specifications
Output Stacking
Capacity Face-Down
150 sheets @80 g/m
2
150 sheets @80 g/m
2
Face-Up 1 sheet 1 sheet
Output Full Sensing Yes Yes
Automatic Duplex
Supporting Built-in Built-in
Media Sizes A4, Letter, Oficio, Folio, Legal A4, Letter, Oficio, Folio, Legal
Media Types Plain Paper, Thin, Thick, Recycled,
Bond, Cardstock, Archive
Plain Paper, Thin, Thick, Recycled,
Bond, Cardstock, Archive
Media Weight
16~32 lb. (60 to 120 g/m
2
) 16~32 lb. (60 to 120 g/m
2
)
ADF/DADF
Capacity
N/A
50 sheets @80 g/m
2
2-sided Document Scanning N/A WorkCentre 3325 only
Paper Size
N/A Width: 142~216mm (5.6"~8.5")
Length: 148~356mm (5.8"~14.0")
Paper Weight
N/A WorkCentre 3315: 16~28 lbs.
WorkCentre 3325: 12.5~28 lb.
Feeding Order
N/A Top to bottom feed
Characteristic Specification
Printing Technology Recording System: Laser electro-photographic system using OPC Drum and direct
transfer to the media.
Exposure System: Laser printhead
Transfer System: Finished image is transferred onto the media
Fusing System: Thermal fusing system by belt
Color Medium Black Toner Cartridge
Print-Quality Mode Standard 600 x 600
Enhanced 1200 x 1200
Non-printable Area Envelope 10 mm (0.4”) from edge (top, bottom, left, and right)
Other Media 4 mm (.16”) from edge (top, bottom, left, and right)
Printer Life Phaser 3330DN
Phaser 3330DNM
WorkCentre 3335
WorkCentre 3345
170,000 pages or 5 years (whichever comes first)
220,000 pages or 5 years (whichever comes first)
170,000 pages or 5 years (whichever comes first)
220,000 pages or 5 years (whichever comes first)
Warm-Up Time
From Sleep Mode
Phaser 3330DN
Phaser 3330DNM
WorkCentre 3335
WorkCentre 3345
35 seconds
35 seconds
As fast as 35 seconds
As fast as 35 seconds
Item Phaser 3330 WorkCentre 3335/3345

Xerox WorkCentre 3335 Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	6.5 s
Print speed (black, normal quality, A4/US Letter)	33 ppm
Maximum copy resolution	600 x 600 DPI
Time to first copy (black, normal)	13 s
Scan to	E-mail, FTP, File, USB
Scanner type	Flatbed & ADF scanner
Output color depth	8 bit
Image formats supported	JPG, TIF
Maximum scan resolution	4800 x 4800 DPI
Faxing	-
Modem speed	33.6 Kbit/s
Auto-redialing	Yes
Fax coding methods	JBIG, JPEG, MH, MMR (Fax coding method), MR
Fax resolution (black)	300 x 300 DPI
Fax speed dialing (max numbers)	200
Maximum duty cycle	50000 pages per month
Page description languages	PCL 5e, PCL 6, PostScript 3
Printer management	IP Filtering, Secure IPP, SS, Secure HTTPS (SSL/TLS)
Internal memory	1500 MB
Processor frequency	1000 MHz
Total input capacity	300 sheets
Total output capacity	150 sheets
Maximum input capacity	850 sheets
Auto document feeder (ADF) input capacity	50 sheets
Storage temperature (T-T)	0 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	20 - 80 %
Display	LCD
Product color	Blue, White
Market positioning	Business
Certification	CE Mark applicable to Low Voltage Directive (2006/95/EC), EMC Directive 2004/108/EC, FCC Part 15, Class B, FCC Part 68, GOST, GS Mark, R&TTE Directive 1999/5/EC, UL 60950-1/CSA 60950-1-07, 2nd Edition
Sustainability certificates	ENERGY STAR
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (average operating)	700 W
Standard interfaces	Ethernet, USB, Wireless LAN
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print
Paper tray media types	Card stock, Plain paper, Recycled paper
Maximum ISO A-series paper size	A4

Weight and Dimensions

Depth	420.6 mm
Width	414.6 mm
Height	449 mm
Weight	15510 g
