WorkCentre 7220-7225 Information Assurance Disclosure Paper
Ver. 1.0, January 2013 Page 6 of 61
2. Device Description
This product consists of an in put document handler and scanner, marking engine including paper path, controller,
and user interface.
Figure 2-1 WorkCentre 7220/7225 Multifunction System
Document Feeder & Scanner
Graphical User
Interface
(GUI)
Front Panel
USB port
