8-19
EXPLODED VIEW & PA RTS LIST
Service Manual
WorkCentre PE16 June 2003
Fuser Assembly Parts List
No. Description Part Number Q’ty Remark
0 AS-FUSER 110V 126 N 00214 1 110V
AS-FUSER 220V 126 N 00215 1 220V
1 COVER-M-FUSER * 1 Not Spared
2 HOLDER-M-PLATE CLAW * 4 Not Spared
3 SPRING ETC-CLAW * 4 Not Spared
4 PMO-ROLLER EXIT * 2 Not Spared
5 SPRING ETC-FUSER EXIT * 2 Not Spared
6 THERMOSTAT-150 130 N 01265 1
7 PMO-GEAR_EXIT_DRV16 * 1 Not Spared
8 GEAR-IDLE 23 * 1 Not Spared
9 RING-CS * 1 Not Spared
10 GEAR-RDCN 25/15 007 N 01213 1
11 IPR-ELECTRODE_LAMP * 1 Not Spared
12 ELECTRODE-WIRE_L * 1 Not Spared
13 THERMISTOR-NTC 130 N 01266 1
14 ELECTRODE-WIRE_R * 1 Not Spared
15 CBF HARNESS-FUSER 110V 152 N 11464 1 110V (WHITE)
CBF HARNESS-FUSER 220V 152 N 02013 1 220V (BLACK)
16 GEAR-FUSER, Z37 007 N 01205 1
17 BUSH-M-HR L * 1 Not Spared
18 ROLLER-HEAT 022 N 01610 1
19 BUSH-M-HR R 016 N 00262 1
20 LAMP-HALOGEN 122 N 00231 1 110V
LAMP-HALOGEN 122 N 00229 1 220V
21 ROLLER-M-EXIT F/UP * 1 Not Spared
22 ROLLER-PRESSURE 022 N 01611 1
23 BEARING-PRESSURE/R * 2 Not Spared
24 SPRING-CS * 2 Not Spared
25 PMO-BUSHING TX * 3 Not Spared
26 HOLDER-ACTUATOR * 1 Not Spared
27 PMO-ACTUATOR_EXIT 120 N 00428 1
28 IPR-P-FRAME_FUSER * 1 Not Spared
29 GUIDE-M-INPUT * 1 Not Spared
30 SPRING-TS * 1 Not Spared
31 RMO-RUBBER_EXIT * 2 Not Spared
32 NUT-HEXAGON * 5 Not Spared
33 LABEL(P)-CAUTION, HOT_FUSER * 1 Not Spared
34 COVER-M-EXIT LOWER * 1 Not Spared
35 PLATE-P-CLAW * 4 Not Spared
To Next Page
