Xerox WorkCentre PE16 Service Manual

7-4
Troubleshooting
WorkCentre PE16
Service Manual
July 2003
7.1.7 Paper rolled in the OPC
• Description Paper is rolled up in the OPC.
Check and Cause Solution
1. Paper is out of specification.
2. Paper is curled.
1. Use recommend paper.
2. How to remove the rolled paper in the OPC.
• Remove the paper while turning the OPC against
the ongoing direction.
• Clean fingerprints on the OPC softly with soft
cloth dampened with IPA(Isopropyl Alcohol) or tis-
sue.
7.1.8 Defective ADF
• Description ADF (Automatic document Feeder) is not operating properly.
Check and Cause Solution
1. Check if ADF rubber and HOLDER rubber are dam-
aged.
2. Check if the document sensors of ADF Ass’y
(3 paper sensors) are normal.
1. Replace the contaminated or damaged part.
2. Replace the ADF ASS’Y.
