Replacing the Drum Ca
rtridge
Xerox CopyCentre/WorkCentre/WorkCentre Pro
123/128 User Guide
305
6.
Close the Cover A until it
latches, and then close the
bypass tray
.
7.
Close the front cover
.
304
