7
Installation
11. Slide the toner cartridge into the copier
until it locks into place.
12. Close the copier by gently pushing down
the upper half.
13. Lift and pull open the paper tray. Turn
and remove the pressure plate lock.
CAUTION: Paper will misfeed if the
pressure plate lock is not removed.
14. Press the copier release lever to open the
copier. Store the pressure plate lock in
the location shown.
Note: Save the pressure plate lock. It will
be needed if the copier has to be shipped for
servicing.
15. Load copy paper into the tray.
• Refer to the Loading Copy Paper
section for additional information.
• Do not fill above the max line.
16. Push the paper tray firmly back into the
copier.
Step 17 for XC855/ XC875/ XC1044/
XC1045/ XC1245 copiers only
17. Inset the front tab of the SDF exit tray into
the front notch. Slide the tray to the front,
and then insert the rear tabs into the rear
notches.
To Next Page
