21
Copying Oversized Documents
The document cover may be removed in order to position an oversized
document on the document glass.
1. Lift the document cover straight up.
Note: Do not leave the cover off for
extended periods of time.
2. Reattach the document after use.
Bound Original Copying
(XC822/ XC830/ XC855/ XC875/ XC1033/ XC1044/ XC1045/ XC1245)
This can be used to copy facing pages of a document onto separate
sheets of paper. The maximum size is B4 (254x356mm).
1. Align the centre of the document with the
book symbol at the centre front of the
document glass and the green arrow on
the left registration guide.
2. Select Bound Original Copying mode,
and any other features.
• Reduction/Enlargement is still possible.
• 50 is the maximum copy quantity.
• • XC822/ XC830/ XC855/ XC1033
XC1044 copiers only: the Paper Tray
Bypass cannot be used for bound
original copying.
3. Press Start.
• The left page will be copied first.
To Next Page
