Chapter 3
Card Component Description
This chapter provides a funconal descripon of the components of the Alveo™ U200/U250
Data Center accelerator card.
UltraScale+ FPGA
The Alveo U200 accelerator card is populated with the Virtex
®
UltraScale+™ XCU200-
L2FSGD2104E FPGA.
The Alveo U250 accelerator card is populated with the Virtex UltraScale+ XCU250-
L2FIGD2104E FPGA.
For more informaon about Virtex
®
UltraScale+™ FPGAs, see the Virtex UltraScale+ FPGA Data
Sheet: DC and AC Switching Characteriscs (DS923).
DDR4 DIMM Memory
Four independent dual-rank DDR4 interfaces are available. The card is populated with four
socketed single-rank Micron MTA18ASF2G72PZ-2G3B1IG 16GB DDR4 RDIMMs. Each DDR4
DIMM is 72 bits wide (64-bits plus support for ECC).
The detailed FPGA and DIMM pin connecons for the feature described in this secon are
documented in the Alveo U200/U250 accelerator card XDC le.
For more details about the Micron DDR4 DIMM, see the Micron MTA18ASF2G72PZ-2G3B1IG
data sheet at the Micron website: hp://www.micron.com.
Quad SPI Flash Memory
The Quad SPI device provides 1 Gb of nonvolale storage.
• Part number: MT25QU01GBBB8E12-0SIT (Micron)
Chapter 3: Card Component Description
UG1289 (v1.1.1) November 20, 2019 www.xilinx.com
Alveo U200 and U250 Accelerator Cards 16
Send Feedback
