Figure 1: Alveo U200 Data Center Accelerator Card (Passive Cooling)
X23434-102419
CAUTION! The Alveo U200/U250 accelerator card with passive cooling is designed to be installed into a data
center server, where controlled air ow provides direct cooling. Due to the card enclosure, switches are not
accessible and LEDs are not visible (except for the triple-LED module DS3 that protrudes through the le front
end PCIe bracket). The card details in this user guide are provided to aid understanding of the card features. If
the cooling enclosure is removed from the card and the card is powered-up, external fan cooling airow MUST
be applied to prevent over-temperature shut-down and possible damage to the card electronics. Removing the
cooling enclosure voids the board warranty.
See Appendix C: Addional Resources and Legal Noces for references to documents, les, and
resources relevant to the Alveo U200/U250 accelerator cards.
