Xilinx ML605 Hardware User's Guide

14 www.xilinx.com ML605 Hardware User Guide
UG534 (v1.9) February 26, 2019
Chapter 1: ML605 Evaluation Board
The numbered features in Figure 1-2 correlate to the features and notes listed in Table 1-1.
Table 1-1: ML605 Features
Number Feature Notes
Schematic
Page
1 Virtex-6 FPGA XC6VLX240T-1FFG1156 2 - 12
2 DDR3 SODIMM Micron 512 MB MT4JSF6464HY-1G1 15
3 128 Mb Platform Flash XL Xilinx XCF128X-FTG64C 25
4 Linear BPI Flash Numonyx JS28F256P30T95 26
5
System ACE CF controller, CF
connector
Xilinx XCCACE-TQ144I
(bottom of board)
13
6
JTAG cable connector (USB
Mini-B)
USB JTAG download circuit 46
7
Clock generation
200 MHz OSC, oscillator socket, SMA
connectors
30
a. 200 MHz oscillator (on
backside)
SiTime 200 MHz 2.5V LVDS OSC 30
b. Oscillator socket, single-
ended
MMD Components 66 MHz 2.5V 30
c. SMA connectors SMA pair 30
d. MGT REFCLK SMA
connectors
SMA pair 30
8GTX RX/TX port SMA x4 30
9
PCIe Gen1 (8-lane),
Gen2 (4-lane)
Card edge connector, 8-lane 21
10 SFP connector and cage AMP 136073-1 23
11
Ethernet (10/100/1000) with
SGMII
Marvell M88E1111 EPHY 24
12
USB Mini-B, USB-to-UART
bridge
Silicon Labs CP2103GM bridge 33
13
USB-A Host, USB Mini-B
peripheral connectors
Cypress CY7C67300-100AXI
controller
27
14 Video - DVI connector Chrontel CH7301C-TF Video codec 28, 29
15
IIC NV EEPROM, 8 Kb
(on backside)
ST Microelectronics M24C08-
WDW6TP
32
16
Status LEDs 13, 24, 31
a. Ethernet status Right-angle link rate and direction
LEDs
24
b. FPGA INIT, DONE Init (red), Done (green) 31
c. System ACE CF status Status (green), Error (red) 13
