Xilinx ML605 Hardware User's Guide

ML605 Hardware User Guide www.xilinx.com 63
UG534 (v1.9) February 26, 2019
Detailed Description
E27 FMC_HPC_HB09_P AL34 F26 FMC_HPC_HB04_N AL33
E28 FMC_HPC_HB09_N AK34 F28 FMC_HPC_HB08_P AK33
E30 FMC_HPC_HB13_P AH33 F29 FMC_HPC_HB08_N AK32
E31 FMC_HPC_HB13_N AH32 F31 FMC_HPC_HB12_P AJ31
E33 FMC_HPC_HB19_P AL31 F32 FMC_HPC_HB12_N AJ32
E34 FMC_HPC_HB19_N AK31 F34 FMC_HPC_HB16_P AH29
F35 FMC_HPC_HB16_N AH30
G2 FMC_HPC_CLK1_M2C_P AP20 H2 FMC_HPC_PRSNT_M2C_L
(1)
AP25
G3 FMC_HPC_CLK1_M2C_N AP21 H4 FMC_HPC_CLK0_M2C_P K24
G6 FMC_HPC_LA00_CC_P AF20 H5 FMC_HPC_CLK0_M2C_N K23
G7 FMC_HPC_LA00_CC_N AF21 H7 FMC_HPC_LA02_P AC20
G9 FMC_HPC_LA03_P AC19 H8 FMC_HPC_LA02_N AD20
G10 FMC_HPC_LA03_N AD19 H10 FMC_HPC_LA04_P AF19
G12 FMC_HPC_LA08_P AK22 H11 FMC_HPC_LA04_N AE19
G13 FMC_HPC_LA08_N AJ22 H13 FMC_HPC_LA07_P AK21
G15 FMC_HPC_LA12_P AM21 H14 FMC_HPC_LA07_N AJ21
G16 FMC_HPC_LA12_N AL21 H16 FMC_HPC_LA11_P AM22
G18 FMC_HPC_LA16_P AP22 H17 FMC_HPC_LA11_N AN22
G19 FMC_HPC_LA16_N AN23 H19 FMC_HPC_LA15_P AM23
G21 FMC_HPC_LA20_P AK23 H20 FMC_HPC_LA15_N AL23
G22 FMC_HPC_LA20_N AL24 H22 FMC_HPC_LA19_P AN25
G24 FMC_HPC_LA22_P AP27 H23 FMC_HPC_LA19_N AN24
G25 FMC_HPC_LA22_N AP26 H25 FMC_HPC_LA21_P AN29
G27 FMC_HPC_LA25_P AN28 H26 FMC_HPC_LA21_N AP29
G28 FMC_HPC_LA25_N AM28 H28 FMC_HPC_LA24_P AN30
G30 FMC_HPC_LA29_P AL28 H29 FMC_HPC_LA24_N AM30
G31 FMC_HPC_LA29_N AK28 H31 FMC_HPC_LA28_P AK27
G33 FMC_HPC_LA31_P AL29 H32 FMC_HPC_LA28_N AJ27
G34 FMC_HPC_LA31_N AK29 H34 FMC_HPC_LA30_P AJ24
G36 FMC_HPC_LA33_P AH23 H35 FMC_HPC_LA30_N AK24
G37 FMC_HPC_LA33_N AH24 H37 FMC_HPC_LA32_P AG25
Table 1-28: VITA 57.1 FMC HPC Connections (Cont’d)
J64 FMC
HPC Pin
Schematic Net Name
U1 FPGA
Pin
J64 FMC
HPC Pin
Schematic Net Name
U1 FPGA
Pin
