62 www.xilinx.com ML605 Hardware User Guide
UG534 (v1.9) February 26, 2019
Chapter 1: ML605 Evaluation Board
C11 FMC_HPC_LA06_N AG21 D12 FMC_HPC_LA05_N AH22
C14 FMC_HPC_LA10_P AM20 D14 FMC_HPC_LA09_P AM18
C15 FMC_HPC_LA10_N AL20 D15 FMC_HPC_LA09_N AL18
C18 FMC_HPC_LA14_P AN19 D17 FMC_HPC_LA13_P AP19
C19 FMC_HPC_LA14_N AN20 D18 FMC_HPC_LA13_N AN18
C22 FMC_HPC_LA18_CC_P AH25 D20 FMC_HPC_LA17_CC_P AN27
C23 FMC_HPC_LA18_CC_N AJ25 D21 FMC_HPC_LA17_CC_N AM27
C26 FMC_HPC_LA27_P AP30 D23 FMC_HPC_LA23_P AL26
C27 FMC_HPC_LA27_N AP31 D24 FMC_HPC_LA23_N AM26
C30 IIC_SCL_MAIN_LS
(1)
AK9 D26 FMC_HPC_LA26_P AM25
C31 IIC_SDA_MAIN_LS
(1)
AE9 D27 FMC_HPC_LA26_N AL25
D29 FMC_HPC_TCK_BUF
(2)
U88.15
D30 FMC_TDI_BUF
(2)
J17.1
D31 FMC_HPC_TDO
(2)
J17.3
D33 FMC_TMS_BUF
(2)
U88.17
E2 FMC_HPC_HA01_CC_P AD29 F1 FMC_HPC_PG_M2C_LS
(1)
J27
E3 FMC_HPC_HA01_CC_N AC29 F4 FMC_HPC_HA00_CC_P AE33
E6 FMC_HPC_HA05_P AB27 F5 FMC_HPC_HA00_CC_N AF33
E7 FMC_HPC_HA05_N AC27 F7 FMC_HPC_HA04_P AB28
E9 FMC_HPC_HA09_P AB30 F8 FMC_HPC_HA04_N AC28
E10 FMC_HPC_HA09_N AB31 F10 FMC_HPC_HA08_P AG31
E12 FMC_HPC_HA13_P AE31 F11 FMC_HPC_HA08_N AF31
E13 FMC_HPC_HA13_N AD31 F13 FMC_HPC_HA12_P AD32
E15 FMC_HPC_HA16_P AC33 F14 FMC_HPC_HA12_N AE32
E16 FMC_HPC_HA16_N AB33 F16 FMC_HPC_HA15_P AB32
E18 FMC_HPC_HA20_P V32 F17 FMC_HPC_HA15_N AC32
E19 FMC_HPC_HA20_N V33 F19 FMC_HPC_HA19_P U33
E21 FMC_HPC_HB03_P AL30 F20 FMC_HPC_HA19_N U32
E22 FMC_HPC_HB03_N AM31 F22 FMC_HPC_HB02_P AP32
E24 FMC_HPC_HB05_P AN33 F23 FMC_HPC_HB02_N AP33
E25 FMC_HPC_HB05_N AN34 F25 FMC_HPC_HB04_P AM33
Table 1-28: VITA 57.1 FMC HPC Connections (Cont’d)
J64 FMC
HPC Pin
Schematic Net Name
U1 FPGA
Pin
J64 FMC
HPC Pin
Schematic Net Name
U1 FPGA
Pin
