Detailed Description
•4 differential clocks
Note:
The ML605 board VADJ voltage for the FMC HPC and LPC connectors (J64 and J63) is fixed
at 2.5V (non-adjustable). The 2.5V rail cannot be turned off. The ML605 VITA 57.1 FMC interfaces
are compatible with 2.5V mezzanine cards capable of supporting 2.5V VADJ.
Table 1-28 shows the VITA 57.1 FMC HPC connections. The connector pinout is in
Appendix B, VITA 57.1 FMC LPC (J63) and HPC (J64) Connector Pinout.
Any signal named FMC_HPC_xxxx that is wired between a U1 FPGA pin and some other
device does not appear in this table.
Table 1-28: VITA 57.1 FMC HPC Connections
J64 FMC
HPC Pin
Schematic Net Name
U1 FPGA
Pin
J64 FMC
HPC Pin
Schematic Net Name
U1 FPGA
Pin
A2 FMC_HPC_DP1_M2C_P AE3 B12 FMC_HPC_DP7_M2C_P AP5
A3 FMC_HPC_DP1_M2C_N AE4 B13 FMC_HPC_DP7_M2C_N AP6
A6 FMC_HPC_DP2_M2C_P AF5 B16 FMC_HPC_DP6_M2C_P AM5
A7 FMC_HPC_DP2_M2C_N AF6 B17 FMC_HPC_DP6_M2C_N AM6
A10 FMC_HPC_DP3_M2C_P AG3 B20 FMC_HPC_GBTCLK1_M2C_P AK6
A11 FMC_HPC_DP3_M2C_N AG4 B21 FMC_HPC_GBTCLK1_M2C_N AK5
A14 FMC_HPC_DP4_M2C_P AJ3 B32 FMC_HPC_DP7_C2M_P AP1
A15 FMC_HPC_DP4_M2C_N AJ4 B33 FMC_HPC_DP7_C2M_N AP2
A18 FMC_HPC_DP5_M2C_P AL3 B36 FMC_HPC_DP6_C2M_P AN3
A19 FMC_HPC_DP5_M2C_N AL4 B37 FMC_HPC_DP6_C2M_N AN4
A22 FMC_HPC_DP1_C2M_P AD1
A23 FMC_HPC_DP1_C2M_N AD2
A26 FMC_HPC_DP2_C2M_P AF1
A27 FMC_HPC_DP2_C2M_N AF2
A30 FMC_HPC_DP3_C2M_P AH1
A31 FMC_HPC_DP3_C2M_N AH2
A34 FMC_HPC_DP4_C2M_P AK1
A35 FMC_HPC_DP4_C2M_N AK2
A38 FMC_HPC_DP5_C2M_P AM1
A39 FMC_HPC_DP5_C2M_N AM2
C2 FMC_HPC_DP0_C2M_P AB1 D4 FMC_HPC_GBTCLK0_M2C_P AD6
C3 FMC_HPC_DP0_C2M_N AB2 D5 FMC_HPC_GBTCLK0_M2C_N AD5
C6 FMC_HPC_DP0_M2C_P AC3 D8 FMC_HPC_LA01_CC_P AK19
C7 FMC_HPC_DP0_M2C_N AC4 D9 FMC_HPC_LA01_CC_N AL19
C10 FMC_HPC_LA06_P AG20 D11 FMC_HPC_LA05_P AG22
