Xilinx SP605 User Guide

SP605 Hardware User Guide www.xilinx.com 57
UG526 (v1.1.1) February 1, 2010
Appendix A
Default Jumper and Switch Settings
Table A-1 shows the default switch settings and Table A-2, page 58 shows the default
jumper settings for the SP605.
Tabl e A - 1 : Default Switch Settings
REFDES Function/Type Default
SW2 Board power slide-switch off
SW1
FPGA mode 2-pole DIP switch, Slave SelectMAP
default selects System ACE CF configuration
2 M1 = 1 on
1M0 = 0off
S1
System ACE CF configuration and image select
4-pole DIP switch
4SysAce Mode = 1on
3 SysAce CFGAddr2 = 0 off
2 SysAce CFGAddr1 = 0 off
1 SysAce CFGAddr0 = 0 off
S2
User GPIO 4-pole DIP switch
4off
3off
2off
1 off
