Table 10: MSP430 TCA6416A U24 I/O Expander Connections (cont'd)
TCA6416A U24 I/O Expander Addr. 0b0100000, 0x40
Port # Schematic Net Name DIR Connected Device
P11 1VCURSNS_ALERT IN U33 INA226 POWER MONITOR ON VCCINT_1V
P12 NOT USED IN N/A
P13 M0_0 IN U1 FPGA CONFIG. BANK 0 MODE M0
P14 M1_0 IN U1 FPGA CONFIG. BANK 0 MODE M1
P15 M2_0 IN U1 FPGA CONFIG. BANK 0 MODE M2
P16 FMC_PRSNT_M2C_LT IN J21 FMC LPC
P17 PGOOD_VADJ IN U40 MP8756G VADJ regulator
The TI TCA9548 and TCA6416 data sheets are on the Texas Instruments website. The detailed
FPGA connecons for the feature described in this secon are documented in the SP701 board
XDC le, referenced in Appendix B: Xilinx Design Constraints
HDMI Video Output
[Figure 2, callout 12]
The SP701 board provides a HDMI video output using the Analog Devices ADV7511KSTZ-P
HDMI transmier (U18). The HDMI output is provided on a Molex 47151-1001 HDMI type-A
connector (J13). The ADV7511 is wired to support 1080P 60 Hz, YCbCr 4:2:2 encoding using
24-bit input data mapping.
The SP701 board supports the following HDMI device interfaces:
• 24 data lines
• Independent VSYNC, HSYNC
• Single-ended input CLK
• Interrupt Out Pin to FPGA
• I2C
• SPDIF
The HDMI output interface is shown in the following gure.
Chapter 3: Board Component Descriptions
UG1319 (v1.0) July 12, 2019 www.xilinx.com
SP701 Board User Guide 28
