Chapter 3
Board Component Descriptions
Overview
This chapter provides a detailed functional description of board components and features.
Table 2-1 identifies the components, references the respective schematic page numbers,
and links to the corresponding detailed functional description in this chapter. Component
locations are shown in Table 2-1.
Component Descriptions
Virtex UltraScale+ XCVU9P-L2FSGD2104E FPGA
[Figure 2-1, callout 1]
The VCU1525 board is populated with the Virtex® UltraScale+™ XCVU9P-L2FSGD2104E
FPGA.
For more information on Virtex UltraScale+ FPGAs, see Virtex UltraScale+ FPGA Data Sheet:
DC and AC Switching Characteristics (DS923) [Ref 2].
I/O Voltage Rails
There are 13 I/O banks available on the XCVU9P-L2FSGD2104E FPGA and the VCU1525
board.
