Page #10 background imageLoading...
Page #10 background image
10 www.xilinx.com Virtex-5 LXT/SXT/FXT FPGA Prototype Platform
UG229 (v3.0.1) May 21, 2008
Overview
R
Onboard battery holder
One low-voltage, 14-pin, DIP crystal oscillator
The kit contains headers that can be soldered to the breakout area, if desired. These headers
are useful with certain types of oscilloscope probes for either connecting function
generators or wiring pins to the prototype area.
The Virtex-5 LXT/SXT/FXT FPGA prototype platform (the board) contains a DUT FPGA,
one SPI, one BPI, and one In-System Programmable Configuration PROM (ISPROM). The
ISPROM can hold up to 33,554,432 bits. The SPI Serial Flash holds up to 64 Mb. The BPI
holds up to 256 Mb. The DUT can be configured from any one of the following:
ISPROM
SPI device
BPI device
Configuration ports (Parallel Cable III/IV cable)
In addition to the ISPROM and the configuration ports, there are upstream connectors and
downstream connectors. The upstream connectors can be connected to configure the DUT
by using the System ACE configuration solution or by chaining another board. The
downstream connectors can be used to connect to another board in a chain for serial
configuration. A maximum of two boards can be chained together.
Package Contents
Virtex-5 LXT/SXT/FXT prototype platform board
User guide
Device vacuum tool
Headers for test points
One low-voltage, 14-pin, dual-inline package (DIP) crystal oscillator
Four SMA-to-SMA cables
Additional Information
Additional information and support material is located at:
FF665: AFX-FF665-500 platform
FF1136: AFX-FF1136-500 platform
FF1738: AFX-FF1738-500 platform
This information includes:
Current version of this user guide in PDF format
Full schematics in PDF format and ViewDraw schematic format
PC board layout in Allegro format
Gerber files for the PC board (Many free or shareware Gerber file viewers are available on
the Internet for viewing and printing these files.)
For information about the Virtex-5 family of FPGA devices, including product highlights,
data sheets, user guides, and application notes, see the Virtex-5 website at
www.xilinx.com/virtex5
. Additional information is available from the data sheets and
application notes from the component manufacturers.
