Virtex-5 LXT/SXT/FXT FPGA Prototype Platform www.xilinx.com 23

UG229 (v3.0.1) May 21, 2008

Detailed Description

14. User LEDs (Active-High)

There are 16 active-High user LEDs on the board. Before configuration, the LEDs reflect the

status of the configuration mode pins. During configuration, the LEDs are in a high-

impedance condition. After configuration, the LEDs are available to the user and reflect the

status of pins D0-D7 and D24-D31 (corresponding to LED 0- LED 15). Table 9 shows the

LED assignments.

Tabl e 9: LED Assignments and Corresponding I/O

Pin Number For Package Type

LED After Configuration FF665 FF1136 FF1738

Available as user LEDs

E25 A33 G42

1 E26 B32 F42

2 G26 C33 G41

3 F25 B33 F41

4 G25 D32 J41

5H26 C32 H41

6 G24 D34 K42

7 F24 C34 J42

8 K21 H33 Y40

9 E23 G32 L40

10 F22 E34 M41

11 F23 F33 L42

12 H22 E33 N41

13 G22 E32 M42

14 J23 F34 P40

15 H23 G33 N40
