Xilinx Zynq-7000 Getting Started Guide

ZC702 and ZVIK Getting Started Guide www.xilinx.com 33
UG926 (v6.0) December 17, 2013
Running the Qt-Based GUI Application Demonstration
3. Wait for the ZC702 board to be configured and booted with Linux. The XILINX ZYNQ
banner appears on the display monitor after approximately two minutes as shown in
Figure 3-5.
4. The Qt-based video demonstration application starts. The GUI application shows up at
the bottom of the screen (see Figure 3-6).
X-Ref Target - Fi gure 3-5
Figure 3-5: Zynq Banner
UG926_c3_05_111012
X-Ref Target - Figure 3-6
Figure 3-6: Qt-Based GUI to Control the Video Pipeline
UG926_c3_06_102813
Send Feedback
