Zynq UltraScale+ VCU TRD User Guide 34
UG1250 (v2019.1) May 29, 2019 www.xilinx.com
Chapter 3: APU Software Platform
Input Options
The following 4K/1080p video sources (3840 x 2160) are available:
• HDMI: Implemented in the PL
• File: TS/MP4/MKV streams reside in the SD card or USB/SATA drives
• Test Pattern Generator (TPG): Implemented in the PL
• CSI: Implemented in the PL (option: MIPI: MIPI CSI, model LI-IMX274 MIPI-FMC v1.1)
• SDI: Implemented in the PL
•
Stream In: Stream from network or Internet
Codec
• Enc—This option selects encoder in the pipeline.
• Enc-Dec—This option selects encode and decode in the pipeline.
• Pass-through—This option selects displaying the raw video source.
X-Ref Target - Figure 3-10
Figure 3-10: Input Settings
X19923-112718
