Xinje DS3 Series User Manual

04
Same speed checking
speed
rpm
50
1~10000
○
3, 4, 7
5-4-6
05
Reach checking speed
rpm
1000
0~10000
○
3, 4, 7
5-4-10
06
Positioning near output
width
Command
unit
50
0~65535
○
6
5-3-7
07
Servo OFF delay time
ms
0
0~65535
○
All the
modes
5-2-5
08
Brake command output
speed
rpm
30
0~10000
○
All the
modes
5-2-5
09
Brake command
waiting time
ms
500
0~65535
○
All the
modes
5-2-5
10
User-defined output 1
trigger condition
-
0
0~FFFF
○
All the
modes
5-11-7
11
User-defined output 1
trigger condition
comparison value
Related to
the trigger
condition
0
-9999~9999
○
All the
modes
5-11-7
12
0: P5-10≥P5-11, output
SOx
1: P5-10<P5-11, output
SOx
2: P5-10 absolute
value≥ P5-11, output
SOx
3: P5-10 absolute value
<P5-11, output SOx
-
0
0~3
○
All the
modes
5-11-7
13
User-defined output 1
hysteresis loop
Related to
the trigger
condition
0
0~65535
○
All the
modes
5-11-7
14
User-defined output 2
trigger condition
-
0
0~FFFF
○
All the
modes
5-11-7
15
User-defined output 2
trigger condition
comparison value
Related to
the trigger
condition
0
-9999~9999
○
All the
modes
5-11-7
16
0: P5-14≥P5-15, output
SOx
1: P5-14≤ P5-15, SOx
output
2: P5-14 absolute value
≥P5-15, output SOx
3: P5-14 absolute value
<P5-15, output SOx
-
0
0~3
○
All the
modes
5-11-7
17
User-defined output 2
hysteresis loop
Related to
the trigger
condition
0
0~65535
○
All the
modes
5-11-7
18
IO filter time
ms
0
0~10000
○
All the
modes
5-11-8
19
Z phase signal pulse
width
ms
2
2~20
√
All the
modes
5-11-5
20
/S-ON servo signal
0000: signal is always
invalid
0001: input positive
signal from SI1
0002: input positive
signal from SI2
0003: input positive
signal from SI3
0004: input positive
signal from SI4
－
n.0001
n.0000~
n.0015
√
All the
modes
5-2-1
