there is default hysteresis loop 10rpm, please refer to chapter 5-11-4.
5-4-11. Alarm speed
5-4-12. Speed command input dead area voltage
5-5．Speed control (internal speed)
Basic parameter
Parameter
Name
Reference
P0-01
Control mode selection
5--1
P5-20
Servo ON signal /S-ON
5-2-1
P3-05
Internal speed 1
5-5-2
P3-06
Internal speed 2
P3-07
Internal speed 3
P5-27
/5SPD-D internal speed direction selection
5-5-3
P5-28
/SPD-A internal speed direction selection
P5-29
/SPD-B internal speed direction selection
Other parameters
Key word
Parameter
Name
Reference
Proportion
action
P5-21
Proportion action command /P-CON
5-4-4
Zero clamp
P5-31
Zero clamp /ZCLAMP
5-4-5
P3-12
Zero clamp mode
P3-21
Forward alarm speed
Unit
Default setting
Range
Suitable
mode
Change
Effective
1rpm
120% of rated
speed
0~10000
All
Servo
OFF
At once
P3-22
Reverse alarm speed
Unit
Default setting
Range
Suitable
mode
Change
Effective
1rpm
120% of rated
speed
0~10000
All
Servo
OFF
At once
Note: 1. the parameters P3-21 and P3-22 are effective in all the modes.
2. the default value is 120% of rated speed. for example: rated speed is 1500, max speed is 1800; rated
speed is 3000, max speed is 3600.
3. these parameters are related to E-080. When the motor is out of control or the speed keeps rising
caused by external force and over the alarm speed, servo will show E-080 alarm.
P3-03
Speed command input dead area voltage
Unit
Default
setting
Range
Suitable
mode
Modify
Effective
0.001V
0
0~500
1, 2, 4
Any
At once
Note:
(1) When the input speed command voltage is in the range of this parameter, the input command
is seemed to be 0.
(2) If there is fretting after calibrating the deviation, please increase the dead area voltage.
