Xinje DS3E Series

96
Table 1 input terminal distribution
input terminal
Servo model
Setting range
P5-20~P5-36
P5-57~P5-59
DS3 series
n.0000~n.0005
n.0010~n.0015
DS3E series
n.0000~n.0004
n.0010~n.0014
Table 2 output terminal distribution
output terminal
Servo model
Setting range
P5-37~P5-53
DS3 series
n.0000~n.0003
n.0010~n.0013
DS3E series
n.0000~n.0002
n.0010~n.0012
P6: signal parameters (reserved)
P6-XX
Name
Unit
Default
value
Range
Effective
Suitable mode
00~04
-
-
-
-
-
-
P7: communication parameters
P7-
Name
Unit
Default
value
Range
Effective
00
RS485 station no.
—
1
1~255
○
01
RS485 parameters
—
2206
○
10
RS232 station no.
—
1
1~255
11
RS232 parameters
—
2206
○
