Xinje DS3E Series

30
4. Wiring
4-1. Main circuit terminals
L1
L2
.
U
V
W
P+
D
C
P-
L3
 DS3-20P2/4/7-PQA
Terminal
Function
Explanation
L1/L2/L3
Power supply input of
main circuit
Single or 3 phase AC 200～240V,
50/60Hz
●
Vacant terminal
-
U、V、W
Motor terminals
Connect the motor
(Note: the ground line is on the
cooling fin, please check it before
power on!)
P+、D、C
Internal regenerative
resistor
Short P+ and D, disconnect P+ and
C, set P0-24=0
External regenerative
resistor
Connect regenerative resistor
between P+ and C, disconnect P+
and D, set P0-24=1, P0-25= power
value, P0-26= resistor value
P+/P-
Bus terminal
Real-time check the bus voltage,
please take attention of this
terminal
