Xinje DS3E Series Manual

36
（3）DS3 series 5.5KW and 7.5KW servo drive
No.
Name
Explanation
No.
Name
Explanation
1
GND
GND-485
2
A1
RS485+
3
B1
RS485-
4
A2
RS485+
5
B2
RS485-
6
GND
GND-485
7
NC
Reserved
8
NC
Reserved
9
NC
Reserved
（4）DS3E series servo drive
No.
Name
Explanation
No.
Name
Explanation
1
GND
GND-485
2
A1
RS485+
3
B1
RS485-
4
A2
RS485+
5
B2
RS485-
6
GND
GND-485
7
NC
Reserved
8
NC
Reserved
9
NC
Reserved
（5）DS3L series servo drive (DS3L not support frequency division function)
No.
Name
Explanation
No.
Name
Explanation
1
NC
Reserved
2
NC
Reserved
3
NC
Reserved
4
NC
Reserved
5
B-
Encoder output B-
6
A+
Encoder output A+
7
A-
Encoder output A-
8
Z+
Encoder output Z+
9
Z-
Encoder output Z-
10
B+
Encoder output B+
11
NC
Reserved
12
NC
Reserved
13
NC
Reserved
14
NC
Reserved
15
NC
Reserved
-
-
-
