Xinje DS3E Series Manual

59
U0-03
Rotate angle (mechenism angle)
0.1°
U0-04
Rotate angle (electrical angle)
0.1°
U0-05
Bus voltage
V
U0-06
IPM temperature
0.1℃
U0-07
Torque feedback
% of rated
U0-08
Pulse offset value
(0000~9999)*1
Command pulse
U0-09
(0000~65535)*10000
U0-10
Encoder feedback
value
(0000~9999)*1
encoder pulse
U0-11
(0000~65535)*10000
U0-12
Pulse value of input
command
(0000~9999)*1
Command pulse
U0-13
(0000~65535)*10000
U0-14
Position feedback
(0000~9999)*1
Command pulse
U0-15
(0000~65535)*10000
U0-16
Encoder position
(Accumulated)
(0000~9999)*1
encoder pulse
U0-17
(0000~65535)*10000
U0-18
Current, 2-bit decimal/torque current
0.1A
U0-19
Analog input V-REF
0.01V
U0-20
Analog input T-REF
0.01V
U0-21
Input signal status 1
U0-22
Input signal status 2
U0-23
Output signal status 1
U0-24
Output signal status 2
U0-25
Input pulse frequency
(0000~9999)*1
Hz
U0-26
(0000~9999)*10000
U0-27
U-phase current sampling zero value related to current
value
0.01A
U0-28
V-phase current sampling zero value related to current
0.01A
