Xinje DS3E Series Manual

75
03
Enable mode:
0: not enable
1: IO/SON input signal
2: software
enable(panel/Modbus)
panel F1-05 write in 1;
Modbus write 1 to
register 0x2105. Write 0
cancel enable.
3: bus enable (support
motion bus model)
-
1
0~3
○
All the
modes
05
Rotation direction
selection
-
0
0, 1
○
All the
modes
09
Input pulse command
positive direction
-
0
0-1
○
6, 7
10
xxx
□
0: CW/CCW
1: AB
2: P+D
-
2
0~2
○
6, 7
10
xx□
x
0: falling edge is
effective
1: rising edge is effective
-
0
0~1
○
6, 7
11
Pulses per circle low
bit×1
-
0
0~9999
√
6
12
Pulses per circle high
bit×10000
-
1
0~
9999
√
6
13
Numerator of Electronic
gear ratio
-
1
1~
65535
√
6
14
Denomination of
-
1
1~
√
6
