Xinje DS3E Series Manual

82
distribution
0: V-REF is speed
command input
1: V-REF is external
speed limit input, actual
speed limit depend on
external analog speed
limit
2: speed feedforward
01
Rated speed
corresponding to analog
voltage
0.01V
1000
150~3
000
○
1, 2, 4, 6
02
Analog voltage speed
filter
0.01ms
0
0~100
00
√
1, 2, 4, 6
03
Speed command input
dead area voltage
0.01v
0
0~100
√
1, 2, 4, 6
05
Preset speed 1
rpm
0
-9999
~
+9999
√
3
06
Preset speed 2
rpm
0
-9999
~
+9999
√
3
07
Preset speed 3
rpm
0
-9999
~
+9999
√
3
09
Acceleration time
ms
0
0~
65535
○
3, 4
10
Deceleration time
ms
0
0~
○
3, 4
