Xinje DS3E Series Manual

87
Note: (1) setting pulse number = pulse numbers (high byte)×10000+pulse number(low byte)
(2) total 35 segments. Segment 1~12 parameters can be set through operate panel, segment
13~35 can write in parameters through communication (RS232 or RS485).
P5: signal parameter setting
P5-
Name
Unit
Default
Range
Effective
Suitable
mode
00
Positioning
finished width
/COIN
Command
pulse
7
0~
65535
○
6
01
Positioning
finished checking
mode
0: offset absolute
value below
P5-00, output
COIN signal
1: offset below
P5-00 after
command finished,
output COIN
signal
2: command
finished, motor
speed below P5-03
and offset absolute
value below
P5-00, output
-
0
0~3
○
6
