Xinje DS3L Series User Manual

10
Base number
40, 60, 80, 90, 110, 130, 180, 220
Oil seal
Empty
Without oil seal (130ST and above models all
have oil seal, so the model without E)
E
With oil seal (60ST, 80ST model name has
differences)
Feedback
component no.
M
Incremental encoder (2500ppr optical pulse
encoder)
F
Line-saving incremental encoder (2500ppr
optical pulse encoder)
T
17 bits absolute value encoder
N
20 bits absolute value encoder
Performance
parameter no.
First 3 bits mean rated torque, last 2 bits mean rated speed
Such as: 00630: rated torque 0.6N.m, rated speed 3000rpm
06025: rated torque 6.0N.m, rated speed 2500rpm
19015: rated torque 19.0N.m, rated speed 1500rpm
Shaft spec
A
No bond
B
With bond
Power-loss
brake
Vacant
No
Z
With power-off brake
Body length
Vacant
Normal models
S
Short body
Voltage level
2
220V
4
380V
Power
Such as: 0P4: 0.4kW
0P7: 0.75kW
1P5: 1.5KW
Motor shaft
length
Note: only
180ST has
differences
vacant
Normal models
S
Short shaft
