Xinje DS3L Series User Manual

50
U2-07
Hardware version
U2-08
Hardware version
U2-09
Total run time (from the first time power on)
Hour
U2-10
Total run time (from the first time power on)
Minute
U2-11
Total run time (from the first time power on)
Second
U2-12
This time run time (from this time power on)
Hour
U2-13
This time run time (from this time power on)
Minute
U2-14
This time run time (from this time power on)
Second
U2-15
Average output power (count from the first time enable)
1W
U2-16
Average heating power (count from the first time enable)
1W
U2-17
Average bus capacitor filter power
1W
U2-18
Motor accumulative
circles
(0000~9999)*1
circle
U2-19
(0000~9999)*10000
circle
U2-20
Device serial number: low 16 bits
U2-21
Device serial number: high 16 bits
U2-22
Firmware generation date: year
U2-23
Firmware generation date: month/day
U2-24
Firmware generation time: hour/minute
 U0-21 input signal status
 U0-21 input signal 1 assignment
Segment
code
Explanation
Segment
code
Explanation
1
/S-ON servo enable signal
2
/P-CON proportion action command
3
/P-OT forward run prohibited
4
/N-OT reverse run prohibited
5
/ALM-RST alarm reset
6
/P-CL forward side external torque limit
7
/N-CL reverse side external torque
limit
8
/SPD-D internal set speed selection
9
/SPD-A internal set speed
selection
10
/SPD-B internal set speed selection
Note: read the status through communication, the binary value from right to left are related to /S-ON,
/P-CON. 0 means no input, 1 means has input. For example: 0x0001 means /S-ON has input,
0x0201 means /S-ON and /SPD-B has input.
 U0-22 input signal status
/S-ON
/P-CON
/P-OT
/N-OT
/ALM-RST
/SPD-B
/SPD-A
/SPD-D
/N-CL
/P-CL
Light means signal input
Light means no signal input
1
2
3
4
5
6
7
8
9
10
