Xinje DS5E Series Manual

P2- Function Unit Default value Range Effective Suitable mode
83 Fifth notch frequency Hz 5000 50~5000 √ 1|3|5|6|7|8|9|10
84 Fifth notch attenuation 0.1dB 70 50~1000 √ 1|3|5|6|7|8|9|10
85 Fifth notch band width Hz 0 0~1000 √ 1|3|5|6|7|8|9|10
P3-XX：
P3- Function Unit
Default
value
Range Effective Suitable mode
05 Preset speed 1 rpm 0 -9999~9999 √ 3
06 Preset speed 2 rpm 0 -9999~9999 √ 3
07 Preset speed 3 rpm 0 -9999~9999 √ 3
09 Acceleration time ms 200 0~65535 ○ 3|7
10 Deceleration time ms 200 0~65535 ○ 3|7
11
Speed command smooth average
filtering time
ms 0 0~65535 √ 1|2|3|4|5|6|7|8|9|10
12 Zero-speed clamping mode - 0 0~3 ○ 3|7
13 Zero-speed clamping speed rpm 10 0~300 ○ 3|7
14
Forward Maximum Speed
Instruction Limit
rpm 4000 0~10000 ○ 3|5|6|7|10
15
Reverse Maximum Speed
Instruction Limit
rpm 4000 0~10000 ○ 3|5|6|7|10
16
Internal Forward Speed
Limitation in Torque Control
rpm 2000 5~10000 √ 1
17
Internal Reverse Speed
Limitation in Torque Control
rpm 2000 5~10000 √ 1
18 Jogging speed rpm 100 0~1000 ○ 1|3|5|6|7|8|9|10
19 forward warning speed rpm 3000 0~10000 ○ 1|3|5|6|7|8|9|10
20 reverse warning speed rpm 3000 0~10000 ○ 1|3|5|6|7|8|9|10
21 forward alarming speed rpm 4000 0~10000 ○ 1|3|5|6|7|8|9|10
22 reverse alarming speed rpm 4000 0~10000 ○ 1|3|5|6|7|8|9|10
