MS series servo motors are for indoor use. Please use them under the following installation conditions:
Item Description
Use ambient
temperature
-10℃~40℃ (no freeze)
Use ambient
humidity
20%~90%RH (no condensation)
Storage
temperature
-20℃~60℃
Storage
humidity
-20%~90%RH (no condensation)
Protection
level
IP65(MS5)/IP66 (MS6)
2-2-3.Installation cautions
Item Description
Antirust
treatment
◆ Before installation, please wipe the "rust-proof agent" of the extension end of the servo
motor shaft, and then do the relevant rust-proof treatment.
Encoder
cautions
◆ It is forbidden to impact the extension end of the shaft
during installation, otherwise the internal encoder will be
broken.
Encoder
cautions
When the pulley is installed on the servo motor shaft with keyway, the screw hole is used
at the end of the shaft. In order to install the pulley, the double-headed nails are inserted
into the screw holes of the shaft, the washer is used on the surface of the coupling end, and
the pulley is gradually locked with the nut.
◆ For the servo motor shaft with keyway, use the screw hole at the end of the shaft to
17
