Xinje DS5E Series Manual

Servo driver model
Built-in
brake unit
Rmin
(Not less
than this
value)
External regenerative
resistance
(Recommended
resistance value)
External regenerative
resistance
(Recommended
power values)
DS5E/L-20P1-PTA
Built-in
50Ω 50Ω-100Ω Above 200W
DS5E/L-20P2-PTA
DS5E/L-20P4-PTA
40Ω 40Ω-100Ω Above 500W
DS5E/L-20P7-PTA
DS5E/L-21P0-PTA
25Ω 25Ω-50Ω Above 1000W
DS5E/L-21P5-PTA
DS5E/L-22P3-PTA
DS5E/L-22P6-PTA
DS5E-41P0-PTA 75Ω 75Ω-100Ω Above 1000W
DS5E-41P5-PTA 55Ω 55Ω - 100Ω Above 1000W
DS5E-43P0-PTA 55Ω 55Ω - 75Ω Above 1000W
DS5E-43P0-PTA-H 55Ω 55Ω - 75Ω Above 1200W
DS5E-45P5-PTA
25Ω 25Ω - 65Ω Above 2000W
DS5E-45P5-PTA-H
DS5E-47P5-PTA 25Ω 25Ω - 50Ω Above 2000W
DS5E-47P5-PTA-H 22Ω 22Ω - 50Ω Above 2500W
DS5E-411P0-PTA 20Ω 20Ω - 45Ω Above 3000W
DS5E-415P0-PTA 20Ω 20Ω - 45Ω Above 3000W
DS5E-422P0-PTA - 20Ω 20Ω - 30Ω Above 5000W
Note:
(1) The smaller the resistance is, the faster the discharge will be, but the smaller the resistance is, the easier the
breakdown resistance will be. Therefore, please close to the the lower limit but not be less than the lower limit
when choosing the type.
(2) When wiring, please use high-temperature flame-retardant wire, and the regenerative resistance surface can
not contact with the wire.
(3) 22kw servo driver DS5E-422P0-PTA has no built-in brake unit, the external brake unit is optional part. The
model is DBM-4110.
12
