Xinje DS5L Series Manual

P2- Function Unit Default value Range Effective Suitable mode
62
Active Vibration Suppression
gain
% 100 1~1000 √ 1|3|5|6|7|8|9|10
63
Active Vibration Suppression
damping
% 100 0~300 √ 1|3|5|6|7|8|9|10
64
Active Vibration Suppression
frequency 1
- 0 -5000~5000 √ 1|3|5|6|7|8|9|10
65
Active Vibration Suppression
frequency 2
- 0 -5000~5000 √ 1|3|5|6|7|8|9|10
66
The second group of active
vibration suppression damping
- 0 0~1000 √
1|2|3|4|5|6|7|8|9|
10
67
The second group of active
vibration suppression
frequencies
- 20000 10~50000 √
1|2|3|4|5|6|7|8|9|
10
69.0 Notch filter 1 switch - 0 0~1 √ 1|3|5|6|7|8|9|10
69.1 Notch filter 2 switch - 0 0~1 √ 1|3|5|6|7|8|9|10
69.3 Notch filter 3 switch - 0 0~1 √ 1|3|5|6|7|8|9|10
70.0 Notch filter 4 switch - 0 0~1 √ 1|3|5|6|7|8|9|10
70.1 Notch filter 5 switch - 0 0~1 √ 1|3|5|6|7|8|9|10
71 First notch frequency Hz 5000 50~5000 √ 1|3|5|6|7|8|9|10
72 First notch attenuation 0.1dB 70 50~1000 √ 1|3|5|6|7|8|9|10
73 First notch band width Hz 0 0~1000 √ 1|3|5|6|7|8|9|10
74 Second notch frequency Hz 5000 50~5000 √ 1|3|5|6|7|8|9|10
75 Second notch attenuation 0.1dB 70 50~1000 √ 1|3|5|6|7|8|9|10
76 Second notch band width Hz 0 0~1000 √ 1|3|5|6|7|8|9|10
77 Third notch frequency Hz 5000 50~5000 √ 1|3|5|6|7|8|9|10
78 Third notch attenuation 0.1dB 70 50~1000 √ 1|3|5|6|7|8|9|10
79 Third notch band width Hz 0 0~1000 √ 1|3|5|6|7|8|9|10
80 Fourth notch frequency Hz 5000 50~5000 √ 1|3|5|6|7|8|9|10
81 Fourth notch attenuation 0.1dB 70 50~1000 √ 1|3|5|6|7|8|9|10
82 Fourth notch band width Hz 0 0~1000 √ 1|3|5|6|7|8|9|10
98
