Xinje DS5L Series Manual

Normal With brake
MS5S-40STE-C□0030□□-20P1-S01/S02 89.5
119
Low inertia
 MS6 motor
Ø30h7
Ø8h6
15
25± 0. 50
LA
3
a40
6. 2
0
- 0. 1
3
N9
M3 - 6H 8
Motor model
LA±1
Inertia level
Normal
With
brake
MS6H-40C□30B□1-20P1 91
122.9
High inertia
 60 series motor installation dimension Unit: mm
 MS5 motor
Ø50h7
30± 0. 5
3
2
20
2
Ø14h6
LA
8
11
0
- 0. 1
5
0
- 0. 02
5
a60
73
Motor model
LA±1
Inertia level
Normal
With
brake
MS5S-60STE-C□00630□□-20P2-S01/S02 79 114
Low inertia
MS5S-60STE-C□01330□□-20P4-S01/S02 99 134
MS5H-60STE-C□00630□□-20P2-S01/S02 91 126 High inertia
