Xinje DS5L1-20P4-PTA User Manual

1 Selection of servo system
1.1 Selection of servo driver
1.1.1 Model name
DS5 L1-2 P - PTA
Display
Encoder type
T
Communication
encoder
Display
Rated output power
0P1 100W
0P2 200W
0P4 400W
0P7 750W
Display
Product name
DS5 Servo driver
Display
Product series
Display
Rated input voltage
2 AC 220V
L1 Compact model
1.1.2 Description of each part
RS232 port
CN0: pulse,
direction, I/O
signal
CN2: driver
encoder interface
Power supply
Regenerative resistance
Motor
wiring

Xinje DS5L1-20P4-PTA Specifications

General

Brand	Xinje
Model	DS5L1-20P4-PTA
Category	Servo Drives
Language	English
