V5 series inverter
44
19 F requency selector 1
20 F requency selector 2
21 F requency selector 3
22 Terminal control mode
is forcibly enabled
23
C ontrol mode selector 1
24
C ontrol mode selector 2
25
Start traverse operatio n
26 Reset the traverse
operation status
27 Close-loop disabled
28 Pause the PLC
operation
29 PLC disabled
30 Reset PLC stopping
status
31
Frequency reference is
input via CI
32 Counter
s trig signal
input
33 Counter
s zero-
cleaning signal input
34
External interrupt inpu t
35 P ulse frequency inpu t
only valid for X6
36 : A c tual length clea r ing
input
P4.01
Function selection of
input terminal X2
As above
1
2
×
P4.02
Function selection of
input terminal X3
As above
1
3
×
P4.03
Function selection of
input terminal X 4
As above
1
10
×
P4.04
Function selection of
input terminal X 5
As above
1
17
×
P4.05
Function selection of
input terminal X 6
As above
1
18
×
P4.06
Function selection of
input terminal X7 FWD
As above
1
0
×
P4.07
Function selection of
input terminal X8 REV
As above
1
0
×
P4.08
FWD/REV
Operation mode selection
0 2-wire control mode 1
1 2-wire control mode 2
2 3-wire control mode 1
3 3-wire control mode 2
1
0
×
P4.09
UP/DN speed rate
0.01 99.99Hz/s
0.01
1.00Hz/s
P4.10
Bi-direction open-
collector output terminal
OC
0
Inverter
running
RUN
1 Frequency arriving
signal FAR
1
0
×
