Xinje XC2 Series User Manual

3 system structure
3-4．ID Assignment of Expansions
Expansion
Position
Type ID (As Register)
Maximum
points/channels
Digital Input X X100~X137 32 points
Digital Output Y Y100~Y137 32 points
Analog Input ID ID100~ID131 16 channels
Analog Output QD
QD100~QD131
16 channels
Position
1#
Module's Value D D8250~D8259 -
Digital Input X X200~X237 32 points
Digital Output Y Y200~Y237 32 points
Analog Input ID ID200~ID231 16 channels
Analog Output QD
QD200~QD231
16 channels
Position
2#
Module's Value D D8260~D8269 -
Digital Input X X300~X337 32 points
Digital Output Y Y300~Y337 32 points
Analog Input ID ID300~ID331 16 channels
Analog Output QD
QD300~QD331
16 channels
Position
3#
Module's Value D D8270~D8279 -
Digital Input X X400~X437 32 points
Digital Output Y Y400~Y437 32 points
Analog Input ID ID400~ID431 16 channels
Analog Output QD
QD400~QD431
16 channels
Position
4#
Module's Value D D8280~D8289 -
Digital Input X X500~X537 32 points
Digital Output Y Y500~Y537 32 points
Analog Input ID ID500~ID531 16 channels
Analog Output QD
QD500~QD531
16 channels
Position
5#
Module's Value D D8290~D8299 -
Digital Input X X600~X637 32 points
Digital Output Y Y600~Y637 32 points
Analog Input ID ID600~ID631 16 channels
Analog Output QD
QD600~QD631
16 channels
Position
6#
Module's Value D D8300~D8309 -
Digital Input X X700~X737 32 points
Digital Output Y Y700~Y737 32 points
Analog Input ID ID700~ID731 16 channels
Analog Output QD
QD700~QD731
16 channels
Position
7#
Module's Value D D8310~D8319 -
Digital Input X X1000~X1037 32 points
Digital Output Y Y1000~Y1037 32 points
Analog Input ID ID1000~ID1031 16 channels
BD Card
Analog Output QD
QD1000~QD1031
16 channels
