Xinje XC2 Series User Manual

Appendix 1 special soft device list
Temperature control
cycle (unit: 0.1s)
Control cycle’s range is 0.5s～200s, the minimum precision is 0.1s. the write value is the
real temperature control cycle multiply 10. i.e. 0.5s control cycle should write 5, 200s
control cycle should write 2000.
Real value
(unit: 0.1℃)
If users think the environment temperature is different with the display temperature, he can
write in the known temperature value. At the moment of value written in, calculate the
temperature difference δ and save.
Calculate the temperature difference value δ=adjust environment temperature value－
sample temperature value. Unit: 0.1℃.
E.g.: under heat balance status, user test the environmental temperature as 60.0℃ with
mercurial thermometer, the display temperature is 55.0℃ (correspond sample temperature
is 550), temperature difference δ=0. at this time, users write this parameters with 600，
temperature difference δ is re-calculated to be 50 (5℃), then the display temperature =
(sample temperature＋temperature difference δ）/10 =60℃。
**Note: when users write the adjust temperature value, make sure that the temperature is
same with the environment temperature value. This value is very important, once it’s
wrong, temperature difference δ will be wrong, then effect the display temperature
A
uto tune output value
The output when auto tune, use % as the unit, 100 represents 100% of full scale output. 80
represents 80% of full scale output.
Appendix 1-4．Special Flash Register List
1、 I filter
ID Function Initial Value Description
FD8000 input filter time of X port 10 Unit: ms
FD8002 0
FD8003 0
…… 0
FD8009 0
2、 I mapping
ID Function Initial value Description
FD8010 X00 corresponds with I** 0 X0 corresponds with number of
input image I**
FD8011 X01 corresponds with I** 1 Initial values are all decimal
FD8012 X02 corresponds with I** 2
…… ……
FD8073 X77 corresponds with I** 63
3、 O mapping
ID Function Initial value Description
FD8074 Y00 corresponds with I** 0 Y0 corresponds with the number of
output image O**
