Xinje XC2 Series User Manual

8 expansion devices
8-3-1．XC-E8AD
0V
24V
AI0
C0 C1 C2 C3
AI3AI2AI1
. .
VI0 VI1 VI2 VI3
C0 C1 C2 C3
CH NAME SIGNAL CH NAME SIGNAL
AI0 VI0+ voltage input AI1 VI1+ voltage input CH0
C0 VI0- voltage input
CH1
C1 VI1- voltage input
AI2 VI2+ voltage input AI3 VI3+ voltage input CH2
C2 VI2- voltage input
CH3
C3 VI3- voltage input
VI0 AI0+ current input VI1 AI1+ current input CH4
C0 AI0- current input
CH5
C1 AI1- current input
VI2 AI2+ current input VI3 AI3+ current input CH6
C2 AI2- current input
CH7
C3 AI3- current input
Items Voltage input (0CH-3CH) Current input (4CH-7CH)
Analog input bound
DC0～5V、0～10V DC0～20mA、4～20mA
Max input bound
±18V 0～40mA
Digital output bound
14 bits binary data
PID control value
0～K4095
Distinguish Ratio
1/16383（14Bit）
Integrate Precision
0.8%
Convert speed
20ms/channel
Power used by analog
DC24V±10%，100mA
l 14 bits high precision analog input
l 8 channels analog input：The first four channels voltage input (0~5V、
0~10V two kinds)；The left 4 channels current input (0~20mA、4~20 mA
two kinds)
l As special function module of XC, 7 models could be connected at most.
l Support PID auto tune function
Brief Introduction 1
Specification 2
Terminal Arrangement 3
