4 power supply specification and wiring method
4-1．Power Supply Specifications
The power supply specifications of XC series PLC are listed below:
※1：Please use the wire cable thicker than 2mm
2
, to avoid the decrease of voltage;
※2：Even happens the 10ms power off, the PLC can keep working. But when power off for long time or voltage
abnormal decrease, the PLC will stop working, output will be OFF. When power supply recover, the PLC
will RUN automatically.
※3：The grounding terminals on basic units and expansions connect together and use the third type grounding.
1
AC Power Supply
Items Content
Rated Voltage AC100V~240V
Allow Voltage Range AC90V~265V
Rated Frequency 50/60Hz
Allow momentary power off time
Interruption Time≤0.5 AC cycle, interval≥1sec
Impulse Current Below 40A 5mS/AC100V below 60A 5mS/AC200V
Maximum Power Consumption 12W
Power Supply for Sensor 24VDC±10% maximum 400mA
Items Content
Rated Voltage DC24V
Allow Voltage Range DC21.6V~26.4V
Input Current (Only for basic
unit)
120mA DC24V
Allow momentary power off time
10mS DC24V
Impulse Current 10A DC26.4V
Maximum Power Consumption 12W
Power Supply for Sensor 24VDC±10% maximum 400mA
2
DC Power Supply Type
