Xinje XC2 Series User Manual

When program the PLC via XCPPro, users can feel it Humanism and easy to get familiar.
l Switch ladder and instruction list freely
l Offer soft device comment, ladder comment, instruction hint functions etc.
l Offer many types of program interface for special instructions, convenient to write the
instructions.
l Perfect monitor mode: ladder monitor, free monitor, soft devices monitor
l Many windows in one interface, convenient to manage.
※1：For the detailed XCP Pro software application, please refer to 《XC series PLC user manual【software】》.
1-1-2．Expansions
To fulfill the field control requirements better, XC series PLC can work with expansions, each
CPU units can link 7 expansions.
l Diverse Types
Digital I/O expansions, analogue I/O modules, temperature control modules and
function mixed modules etc.
l Compact Size
l DC24V power supply (32I/O modules are AC220V power supply).
l Analogue、temperature modules all include PID tune function.
Easy to Program 3
Expansion Modules 1
Digital I/O
Modules
Power Supply: DC24V
AC220V
Input points: 8-32
Output points: 8-32
Output Type: Relay
Transistor
Analogue I/O
Modules
Power Supply: DC24V
Type: DA、AD
AD/DA
DA channel Nr.：2、4
AD channel Nr.: 4、8
Temperature
Control Modules
Power Supply: DC24V
Temperature: PT100
thermocouple
Temp. Channel Nr.: 6
PID Control: Included
Function Mixed
Modules
Power Supply: DC24V
AD: 3CH
Temperature: 4CH PT100
DA: 2CH
