Xinje XC2 Series User Manual

Modbus network, PLC can be master or slave; XC5 series can build CAN bus; via
T-BOX module can build Ether net; via G-BOX can work with GPRS network;
l High Speed Pulse Output can reach 400Hz
XC series PLC
※
1
are generally equipped 2 pulse output terminals, can output 400KHz
pulse; the special model
※
2
has 4 channels pulse output functions
l Interruption Function
XC series PLC have interruption function, including external interruption, time
interruption and high speed counter interruption; they can meet different requirements.
l Switch I/O points freely
XC series PLC has special switch I/O points function, that is developed in case of
terminals broken, there is no need to change the program;
l C language function block
Write the function block with C language, the program is more secured. Meantime, with
the abundant operation functions, the PLC can realize more functions, which saves great
internal space, improve the program efficiency;
l PID function on CPU units
The CPU units of XC series PLC
※
1
has PID control and auto tune function.
l Sequential Function Block (BLOCK)
In sequential function Block, users can realize the sequential action of instructions. This
function is suitable to apply on pulse output, communication, motion control, inverter's
read/write etc. This function simplify the program editing greatly.
l 24 segments high speed counter interruption
There are 24 segments 32 bits initial value in high speed counter of XC series PLC
※
1 .
Each segment can generate interruption with perfect real time ability, realize electric
cam function;
l PWM pulse width modulation
XC series PLC
※
1
have PWM pulse width modulation function, this function can apply
to DC motor control;
l Frequency testing
XC series PLC
※
1
can realize frequency testing
l Precise Time
XC series PLC
※
1
can realize precise time, the precise timer is a 32 bits timer of 1ms
l Motion Control
XCM series PLC
※
1
are motion control models, can realize circular interpolation, position
control etc.
※1：Here XC series PLC refer to the PLC which can realize the mentioned functions. That's to say, not all XC
series PLC can realize the mentioned function. For details, please refer to Appendix 4.
※2：here the special model refers to XC5-32T-E
