8 expansion devices
0V
24V
A1
C0 C1 C2 C3 C4 C5
A5A4A3A2A0
Y1 .
Y5Y3COM2COM1
COM0
Y0 Y2 Y4
8-3-7．XC-E6TCA-P
CH NAME SIGNAL CH NAME SIGNAL
A0 0CH thermo-resistor input terminal A1 1CH thermo-resistor input terminal
CH0
C0 0CH COM of thermo-resistor input
CH1
C1 1CH COM of thermo-resistor input
A2 2CH thermo-resistor input terminal A3 3CH thermo-resistor input terminal
CH2
C2 2CH COM of thermo-resistor input
CH3
C3 3CH COM of thermo-resistor input
A4 4CH thermo-resistor input terminal A5 5CH thermo-resistor input terminal
CH4
C4 4CH COM of thermo-resistor input
CH5
C5 5CH COM of thermo-resistor input
Y0 Output of CH0 Y1 Output of CH1
Y2 Output of CH2 Y3 Output of CH3
Y4 Output of CH4 Y5 Output of CH5
24V +24V power supply
-
0V COM for power supply
COM0、COM1, COM2: COM for outputs
Terminal Arrangement 3
Brief Introduction 1
Specification 2
●
Support many thermocouple types (K, S, E, N, J, T, R types)
●
Adopt DC-DC power supply isolate design, enhance the anti-interfere ability;
●
The temperature precision is 0.1℃。
●
Set each channel’s PID parameters independently, equipped with separate register space;
●
Support real time PID auto tune function; enable the device to PID auto tune under every
status (cold status, heating status, transition status etc), get the best PID values;
●
Realize data exchange with FROM and TO instructions, enhance the flexibility, reduce the
data exchange quantity, expand the data memory space;
